RUTX12 Tabletop router

RUTX12 Tabletop router
Нема на залиха
RUTX12 Tabletop router
  • Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
  • Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
  • WLAN data transfer rate (max): 867
  • Ethernet LAN data rates: 10/100/1000
  • Ethernet LAN (RJ-45) ports: 5
  • USB port: Yes
Врз основа на 0 коментари. - Напиши коментар
37,175ден.
  • Достапност: Нема на залиха
  • Бренд: TELTONIKA
  • Шифра: 423883
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Teltonika RUTX12. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az. Mobile network generation: 4G, 4G standard: LTE. Security algorithms: DES, IPSEC
  • Vendor Homepage: https://teltonika-networks.com/product/rutx12/
  • Name: WRL ROUTER LTE/RUTX12 TELTONIKA
  • Category Code: WRO
  • Model name: RUTX12
  • Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
  • Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
  • WLAN data transfer rate (max): 867
  • Wi-Fi standards: 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
  • Ethernet WAN: Yes
  • SIM card slot: Yes
  • 3G/4G USB modem compatibility: Yes
  • WAN connection type: RJ-45
  • Ethernet LAN: Yes
  • Ethernet LAN interface type: Gigabit Ethernet
  • Ethernet LAN data rates: 10/100/1000
  • Networking standards: IEEE 802.3/IEEE 802.3af/IEEE 802.3at/IEEE 802.3au/IEEE 802.3az
  • Auto MDI/MDI-X: Yes
  • Dynamic DNS (DDNS): Yes
  • Mobile network generation: 4G
  • 3G: Yes
  • 4G: Yes
  • Dual SIM support: Yes
  • 4G standard: LTE
  • Short Message Service (SMS): Yes
  • Ethernet LAN (RJ-45) ports: 5
  • USB port: Yes
  • Quality of Service (QoS) support: Yes
  • Reset button: Yes
  • Security algorithms: DES/IPSEC
  • Firewall: Yes
  • Access Control List (ACL): Yes
  • Filtering: Yes
  • DHCP client: Yes
  • Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL)
  • Product colour: Silver
  • Housing material: Aluminium
  • LED indicators: Power,Status
  • Product type: Tabletop router
  • Manual: Yes
  • Quick start guide: Yes
  • Certification: CE/RED, EAC, RoHS, WEEE Draft ETSI EN 301 489-1 V2.2.0, Draft EN 301 489-19 V2.1.0, Draft ETSI EN 301 489-52 V1.1.0 EN 61000-4-2:2009 EN 300 511 V12.5.1, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2 EN 61000-4-3:2006 +
  • Antenna design: Internal
  • Antennas quantity: 8
  • Built-in processor: Yes
  • Processor architecture: ARM Cortex A7
  • Processor frequency: 717
  • Processor cores: 4
  • Internal memory: 256
  • Flash memory: 256
  • Safety: IEC 62368-1:2014, EN 50385:2017, EN 62232:2017
  • Power source type: DC
  • Power over Ethernet (PoE): Yes
  • Operating relative humidity (H-H): 10 - 90
  • Operating temperature (T-T): -40 - 75
  • Depth: 95
  • Height: 44
  • Weight: 540
  • Width: 132
  • Harmonized System (HS) code: 85176990
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.003888
  • Unit Calculated Weight: 2
Specifications
3G/4G USB modem compatibilityYes
4G standardLTE
Access Control List (ACL)Yes
Antenna designInternal
Antennas quantity8
Auto MDI/MDI-XYes
Built-in processorYes
CertificationCE/RED, EAC, RoHS, WEEE Draft ETSI EN 301 489-1 V2.2.0, Draft EN 301 489-19 V2.1.0, Draft ETSI EN 301 489-52 V1.1.0 EN 61000-4-2:2009 EN 300 511 V12.5.1, ETSI EN 301 908-1 V11.1.1, ETSI EN 301 908-2 V11.1.2, ETSI EN 301 908-13 V11.1.2 EN 61000-4-3:2006 +
Depth95
DHCP clientYes
Dual SIM supportYes
Dynamic DNS (DDNS)Yes
Ethernet LANYes
Ethernet LAN (RJ-45) ports5
Ethernet LAN data rates10/100/1000
Ethernet LAN interface typeGigabit Ethernet
Ethernet WANYes
FilteringYes
FirewallYes
Flash memory256
Harmonized System (HS) code85176990
Height44
Housing materialAluminium
Internal memory256
LED indicatorsPower,Status
ManualYes
Mobile network generation4G
Networking standardsIEEE 802.3/IEEE 802.3af/IEEE 802.3at/IEEE 802.3au/IEEE 802.3az
Operating relative humidity (H-H)10 - 90
Operating temperature (T-T)-40 - 75
Power over Ethernet (PoE)Yes
Power source typeDC
Processor architectureARM Cortex A7
Processor cores4
Processor frequency717
Product colourSilver
Quality of Service (QoS) supportYes
Quick start guideYes
Reset buttonYes
SafetyIEC 62368-1:2014, EN 50385:2017, EN 62232:2017
Security algorithmsDES/IPSEC
Short Message Service (SMS)Yes
SIM card slotYes
SummaryTeltonika RUTX12. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az. Mobile network generation: 4G, 4G standard: LTE. Security algorithms: DES, IPSEC
Supported network protocolsTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet client, SNMP, MQTT, Wake on LAN (WOL)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
USB portYes
WAN connection typeRJ-45
Weight540
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
Width132
WLAN data transfer rate (max)867
Specs
3GYes
4GYes
Category CodeWRO
Description

Powerful Dual LTE Cat 6 router is designed for mission critical applications. Two simultaneously operational LTE CAT 6 modems can provide speeds up to 600 Mbps with load balancing feature. This makes this device irreplaceable in applications where loosing connection is not an option.

Two LTE modules working simultaneously can provide speeds up to 600 Mbps

Instant failover switching

5 x Gigabit Ethernet with speeds up to 1000 Mbps

Teltonika Remote Management System compatible

Easy to use, secure and feature rich OpenWrt based Operating System

Model nameRUTX12
NameWRL ROUTER LTE/RUTX12 TELTONIKA
PictureUrlhttps://static.elko.cloud/ProductImages/2c4c74a3-c654-4de3-9fa9-ba39c43f6421.Jpeg
Product TypeTabletop router
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/2c4c74a3-c654-4de3-9fa9-ba39c43f6421.Jpeg
Unit Calculated Volume0.003888
Unit Calculated Weight2
Units per Shipping Box1
Vendor Homepagehttps://teltonika-networks.com/product/rutx12/
