NET CAMERA 2MP BOX AI INDOOR/WV-S1136A I-PRO

Technical Specifications

• Summary: i-PRO WV-S1136A. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: Black, White, Form factor: Turret. Minimum illumination: 0.008 lx, Angle of rotation: 270°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Supported graphics resolutions (panoramic camera): 320 x 288 (QVGA), 640 x 480 (VGA), 1280 x 960, 2048 x 1536 (QXGA), White balance (panoramic camera): ATW, AWC
• Vendor Homepage: https://i-pro.com/products_and_solutions/en/surveillance/products/wv-s1136a
• Name: NET CAMERA 2MP BOX AI INDOOR/WV-S1136A I-PRO
• Category Code: FNC
• Form factor: Turret
• Mounting type: Ceiling
• Product colour: Black/White
• International Protection (IP) code: IP66, IP67
• IK code: IK10
• Fog proof: Yes
• Type: IP security camera
• Connectivity technology: Wired
• Placement supported: Indoor
• Dynamic range: 144
• Languages support: English/French/German/Italian/Japanese/Portuguese/Russian/Simplified Chinese/Spanish
• Number of languages: 9
• Minimum illumination: 0.008
• Angle of rotation: 270
• Number of Privacy masking areas: 8
• Number of sensors: 1
• Optical sensor size: 1/2.8
• Sensor type: CMOS
• Supported graphics resolutions (panoramic camera): 1280 x 960/2048 x 1536 (QXGA)/320 x 288 (QVGA)/640 x 480 (VGA)
• White balance (panoramic camera): ATW/AWC
• Optical zoom: 2.5
• Focal length range: 2.9 - 7.3
• Auto focus: Yes
• Fixed focus: Yes
• Focus: Motorized/Manual
• Detect distance (tele): 136.5
• Detect distance (wide): 45.1
• Identify distance (tele): 13.6
• Identify distance (wide): 4.5
• Normal focusing range: 1
• Observe distance (tele): 54.6
• Observe distance (wide): 18
• Recognize distance (tele): 27.3
• Recognize distance (wide): 9
• Night vision: Yes
• Night vision distance: 20
• Maximum resolution: 2688 x 1520
• Total megapixels: 16
• Video compression formats: H.264/H.265
• Video intelligence analytic: Yes
• Noise reduction: Yes
• Back Light Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes
• Image quality adjustment: Brightness
• Audio formats supported: AAC-LC/G.711/G.726
• Voice codecs: AGC
• Audio detection: Yes
• Ethernet LAN: Yes
• Supported network protocols: IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, MQTT IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGM
• Card reader integrated: Yes
• Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC/SD/SDHC/SDXC
• Ethernet LAN (RJ-45) ports: 1
• Intelligent Video Surveillance (IVS) system features: Scene change
• Video motion detection: Yes
• Web browser: Yes
• Power source type: DC,PoE
• Operating temperature (T-T): -40 - 60
• Operating relative humidity (H-H): 10 - 100
• Width: 300
• Depth: 90
• Weight: 3300
• Compliance certificates: National Defense Authorization Act (NDAA)
• Units per Shipping Box: 1
• Unit Calculated Volume: 0.001734
• Unit Calculated Weight: 0.4
