NET CAMERA M4225-LVE DOME/02814-001 AXIS

NET CAMERA M4225-LVE DOME/02814-001 AXIS
NET CAMERA M4225-LVE DOME/02814-001 AXIS
  • Connectivity technology: Wired
  • Zoom capability: Yes
  • Maximum resolution: 1920 x 1080
  • Total megapixels: 2
  • Ethernet LAN: Yes
Врз основа на 0 коментари. - Напиши коментар
45,381ден.
  • Достапност: Има залиха
  • Бренд: AXIS
  • Шифра: 450786
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Axis 02814-001. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.03 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 100°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB
  • Vendor Homepage: https://www.axis.com/products/axis-m4225-lve
  • Name: NET CAMERA M4225-LVE DOME/02814-001 AXIS
  • Category Code: FNC
  • Form factor: Dome
  • Mounting type: Wall
  • Product colour: Black/White
  • LED indicators: Yes
  • Housing material: Plastic/Polycarbonate (PC)
  • International Protection (IP) code: IP66
  • IK code: IK10
  • Weatherproof: Yes
  • Type: IP security camera
  • Connectivity technology: Wired
  • Placement supported: Outdoor
  • PTZ control: Yes
  • PTZ modes: Digital PTZ
  • Auto-tracking: Yes
  • Tour recording: Yes
  • Preset points: Yes
  • Wide Dynamic Range (WDR): Yes
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes
  • Camera pan control: Yes
  • Camera tilt control: Yes
  • Minimum illumination: 0.03
  • Angle of rotation: 360
  • Lens viewing angle, horizontal: 100
  • Lens viewing angle, vertical: 52
  • Tilt angle range: -10 - 65
  • Pan range: -180 - 180
  • Camera pixel size: 2.9
  • Camera shutter speed: 1/20000 - 1.5
  • Signal-to-Noise Ratio (SNR) (panoramic camera): 55
  • Number of sensors: 1
  • Optical sensor size: 1/2.8
  • Sensor type: CMOS
  • Zoom capability: Yes
  • Number of lenses: 1
  • Focal length range: 3.2 - 7.2
  • Auto focus: Yes
  • Maximum aperture number: 2.7
  • Minimum aperture number: 2.9
  • Closest focusing distance: 1
  • Detect distance (tele): 101.8
  • Detect distance (wide): 43.7
  • Identify distance (tele): 10.2
  • Identify distance (wide): 4.4
  • Observe distance (tele): 40.4
  • Observe distance (wide): 17.4
  • Recognize distance (tele): 20.4
  • Recognize distance (wide): 8.8
  • Night vision: Yes
  • Night vision distance: 20
  • LED type: IR
  • Infra-red wavelength: 850
  • Maximum resolution: 1920 x 1080
  • Total megapixels: 2
  • Video formats supported: AVC/H.264/H.265/HEVC/M-JPEG/MPEG4
  • Supported graphics resolutions: 1280 x 960/1920 x 1080 (HD 1080)/320 x 240/640 x 360
  • Frame rate: 30
  • Video streaming: Yes
  • Bit rate control: Variable Bit Rate (VBR)
  • Flip & mirror: Yes
  • Image quality adjustment: Brightness/Contrast/Saturation/Sharpness
  • Text caption overlay: Yes
  • Audio detection: Yes
  • Ethernet LAN: Yes
  • Ethernet interface type: Fast Ethernet
  • Networking standards: IEEE 802.1x/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt
  • Supported network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4
  • Streaming method: Multicast
  • Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
  • Flash memory: 8000
  • RAM capacity: 1000
  • Human and vehicle targets classification: Yes
  • Intelligent Video Surveillance (IVS) system features: Abandoned object/Line crossing detection/Moving object
  • Privacy protection: Yes
  • Security algorithms: EAP-TLS/HTTPS/MSCHAPv2/PEAP/TLS
  • Cloud-managed: Yes
  • Power source type: PoE
  • Power consumption (typical): 2.7
  • Power consumption (max): 10.5
  • Operating temperature (T-T): -30 - 50
  • Storage temperature (T-T): -40 - 65
  • Operating relative humidity (H-H): 10 - 100
  • Storage relative humidity (H-H): 5 - 95
  • Width: 140
  • Depth: 112
  • Height: 126
  • Weight: 540
  • Compliance certificates: BSMI/CE/cUL/EAC/RCM/REACH/RoHS/Trade Agreements Act (TAA)/UKCA/UL/VCCI
  • Number of cameras: 1
  • Sun shield included: Yes
  • Manual: Yes
  • Doesnt contain: Brominated Flame Retardant (BFR)/CFR/PVC
  • Units per Pallet: 0
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.0036
  • Unit Calculated Weight: 0.5
Specifications
Angle of rotation360
Audio detectionYes
Auto focusYes
Auto-trackingYes
Bit rate controlVariable Bit Rate (VBR)
Camera pan controlYes
Camera pixel size2.9
Camera shutter speed1/20000 - 1.5
Camera tilt controlYes
Closest focusing distance1
Cloud-managedYes
Compatible memory cardsMicroSD (TransFlash)/MicroSDHC/MicroSDXC
Compliance certificatesBSMI/CE/cUL/EAC/RCM/REACH/RoHS/Trade Agreements Act (TAA)/UKCA/UL/VCCI
Connectivity technologyWired
Day/night modeYes
Depth112
Detect distance (tele)101.8
Detect distance (wide)43.7
Doesn\'t containBrominated Flame Retardant (BFR)/CFR/PVC
Ethernet interface typeFast Ethernet
Ethernet LANYes
Flash memory8000
Flip & mirrorYes
Focal length range3.2 - 7.2
Form factorDome
Frame rate30
Height126
Housing materialPlastic/Polycarbonate (PC)
Human and vehicle targets classificationYes
Identify distance (tele)10.2
Identify distance (wide)4.4
IK codeIK10
Image quality adjustmentBrightness/Contrast/Saturation/Sharpness
Infra-red wavelength850
Infrared (IR) cut-off filterYes
Intelligent Video Surveillance (IVS) system featuresAbandoned object/Line crossing detection/Moving object
International Protection (IP) codeIP66
LED indicatorsYes
LED typeIR
Lens viewing angle, horizontal100
Lens viewing angle, vertical52
ManualYes
Maximum aperture number2.7
Maximum resolution1920 x 1080
Minimum aperture number2.9
Minimum illumination0.03
Mounting typeWall
Networking standardsIEEE 802.1x/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt
Night visionYes
Night vision distance20
Number of cameras1
Number of lenses1
Number of sensors1
Observe distance (tele)40.4
Observe distance (wide)17.4
Operating relative humidity (H-H)10 - 100
Operating temperature (T-T)-30 - 50
Optical sensor size1/2.8
Pan range-180 - 180
Placement supportedOutdoor
Power consumption (max)10.5
Power consumption (typical)2.7
Power source typePoE
Preset pointsYes
Privacy protectionYes
Product colourBlack/White
PTZ controlYes
PTZ modesDigital PTZ
RAM capacity1000
Recognize distance (tele)20.4
Recognize distance (wide)8.8
Security algorithmsEAP-TLS/HTTPS/MSCHAPv2/PEAP/TLS
Sensor typeCMOS
Signal-to-Noise Ratio (SNR) (panoramic camera)55
Storage relative humidity (H-H)5 - 95
Storage temperature (T-T)-40 - 65
Streaming methodMulticast
SummaryAxis 02814-001. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, White, Form factor: Dome. Minimum illumination: 0.03 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 100°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB
Sun shield includedYes
Supported graphics resolutions1280 x 960/1920 x 1080 (HD 1080)/320 x 240/640 x 360
Supported network protocolsIPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4
Text caption overlayYes
Tilt angle range-10 - 65
Total megapixels2
Tour recordingYes
TypeIP security camera
Video formats supportedAVC/H.264/H.265/HEVC/M-JPEG/MPEG4
Video streamingYes
WeatherproofYes
Weight540
Wide Dynamic Range (WDR)Yes
Width140
Zoom capabilityYes
Specs
Category CodeFNC
Description

AXIS M4225-LVE Dome Camera

This compact, varifocal dome camera offers great images in 2 MP. It comes preinstalled with AXIS Object Analytics, as well as AXIS Audio Analytics to detect and classify specific sounds as well as sudden changes in sound volume.

Great images, every time

AXIS M4225-LVE delivers great image quality in 2 MP. Featuring a varifocal lens with 100°-38° field of view and remote zoom and focus capabilities, it can be adapted for close-ups and overviews without the need for hands-on fine tuning. Thanks to Lightfinder 2.0 and Forensic WDR, it provides details even in challenging light conditions. Plus, OptimizedIR allows for surveillance in total darkness without the need for extra lighting. Furthermore, Axis Zipstream with support for H.264 and H.265 significantly reduces bandwidth and storage requirements without compromising image quality.

Powerful with strong security

Featuring a deep learning processing unit (DLPU), AXIS M4225-LVE lets you run advanced features and powerful analytics on the edge. For instance, it comes preinstalled with AXIS Object Analytics to detect, classify, track, and count objects such as humans and vehicles. It includes an acoustic sensor, so it’s out-of-the-box-ready for AXIS Audio Analytics which can detect and classify specific sounds as well as sudden changes in sound volume. In addition, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations.

Small and discreet

This compact and discreet dome camera blends in with any environment. There’s also a smoked dome available as an accessory, so you can disguise which way the camera is pointing. This IP66- and IK10-rated camera has an operating temperature range from -30°C to 50°C (-22°F to 122°F). Plus, the included weathershield offers extra protection.



  • Great image quality in 2 MP
  • Varifocal lens with remote zoom and focus
  • Lightfinder 2.0, Forensic WDR, and OptimizedIR
  • AI-based audio and video analytics
  • Built-in cybersecurity with Axis Edge Vault

NameNET CAMERA M4225-LVE DOME/02814-001 AXIS
PictureUrlhttps://static.elko.cloud/ProductImages/d0491ea1-e3ae-4963-a708-0737df53a6c9.Jpeg
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/d0491ea1-e3ae-4963-a708-0737df53a6c9.Jpeg
Unit Calculated Volume0.0036
Unit Calculated Weight0.5
Units per Pallet0
Units per Shipping Box1
Vendor Homepagehttps://www.axis.com/products/axis-m4225-lve
