CRS418-8P-8G-2S+RM

CRS418-8P-8G-2S+RM
достава за 24h
CRS418-8P-8G-2S+RM
  • Switch layer: L2/L3
  • Basic switching RJ-45 Ethernet ports quantity: 17
64,766ден.
  • Достапност: Има залиха
  • Бренд: MIKROTIK
  • Шифра: 448630
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
1

Technical Specifications

  • Summary: Mikrotik CRS418-8P-8G-2S+5axQ2axQ-RM. Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 17, Console port: RJ-45. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
  • Vendor Homepage: https://mikrotik.com/product/crs418_8p_8g_2s_wifi#fndtn-specifications
  • Name: NET ROUTER/SWITCH 16PORT SFP+/S4188P8G2S+5AXQ2AXQRM MIKROTIK
  • Category Code: SWI
  • Model: CRS418-8P-8G-2S+RM
  • Model name: CRS418-8P-8G-2S+RM
  • Switch layer: L2/L3
  • Basic switching RJ-45 Ethernet ports quantity: 17
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • SFP+ module slots quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
  • USB Type-A ports quantity: 1
  • Console port: RJ-45
  • Networking standards: IEEE 802.3af/IEEE 802.3at
  • 10G support: Yes
  • Ethernet LAN data rates: 10,100,1000
  • Rack mounting: Yes
  • Form factor: 1U
  • Reset button: Yes
  • International Protection (IP) code: IP20
  • Operating system installed: RouterOS
  • Built-in processor: Yes
  • Processor manufacturer: ARM
  • Processor model: 98DX226S
  • Processor frequency: 2208
  • Internal memory: 1000
  • Flash memory: 128
  • Mean time between failures (MTBF): 200000
  • Power source: AC/PoE
  • Power supply included: Yes
  • AC input voltage: 100 - 240
  • AC input frequency: 50/60
  • Power consumption (typical): 43
  • Power consumption (max): 227
  • Power over Ethernet (PoE): Yes
  • Operating temperature (T-T): -20 - 70
  • Width: 443
  • Depth: 250
  • Height: 44
  • Compliance certificates: CE/EAC/RoHS
  • Units per Pallet: 0
  • Units per Shipping Box: 2
  • Unit Calculated Volume: 0.03186
  • Unit Calculated Weight: 3.9
Specifications
10G supportYes
AC input frequency50/60
AC input voltage100 - 240
Basic switching RJ-45 Ethernet ports quantity17
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Built-in processorYes
Compliance certificatesCE/EAC/RoHS
Console portRJ-45
Depth250
Ethernet LAN data rates10,100,1000
Flash memory128
Form factor1U
Height44
Internal memory1000
International Protection (IP) codeIP20
Mean time between failures (MTBF)200000
Networking standardsIEEE 802.3af/IEEE 802.3at
Operating system installedRouterOS
Operating temperature (T-T)-20 - 70
Power consumption (max)227
Power consumption (typical)43
Power over Ethernet (PoE)Yes
Power supply includedYes
Processor frequency2208
Processor manufacturerARM
Processor model98DX226S
Rack mountingYes
Reset buttonYes
SFP+ module slots quantity2
SummaryMikrotik CRS418-8P-8G-2S+5axQ2axQ-RM. Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 17, Console port: RJ-45. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Switch layerL2/L3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB Type-A ports quantity1
Width443
Specs
Category CodeSWI
Description

The Wi-Fi version of CRS418... with our strongest 4x4 MIMO Wi-Fi 6! L3 HW offloading, quad-core 2.2 GHz ARM CPU, 16x Gigabit Ethernet ports + a Gigabit management port with a direct CPU line, 2x 10G SFP+ ports, PoE-out.

Why settle for just a simple switch when you can have PoE-out, high-speed fiber uplinks, USB storage compatibility, advanced network control/monitoring, and enough processing power even for some routing or L3 HW offloading… in a single 1U device and for the best price on the market?

The CRS418-8P-8G-2S+RM combines 16 Gigabit Ethernet ports (eight of them with PoE-out!), two 10G SFP+ cages, USB 3 connectivity, and a powerful quad-core 2.2 GHz CPU in a clean, durable rackmount enclosure. Also, there’s a Gigabit management port with a direct CPU line.

This is a serious upgrade for anyone looking to replace a jungle of devices with one smart multitasker – built for real routing workloads, high-bandwidth uplinks, and clean cable management. Whether you’re powering up access points and CCTV cameras, running a fast NAS with a bunch of modern workstations, or managing the routing in your mid-sized office, CRS418 handles it all with ease – and on a budget!

Wi-Fi where it matters

2CRS418-8P-8G-2S+5axQ2axQ-RM The all-in-one switch/routing champion also delivers 4×4 MIMO dual-band Wi-Fi 6 – for fast, reliable connectivity wherever you need it. The perfect solution to simplify basement server room setups or medium-sized offices on a tight budget – now you don’t need to carry a separate access point!

We know rackmounts are not famous for great wireless coverage. That’s why the CRS418 Wi-Fi edition includes dedicated holes in the back for pigtails, so you can place antennas outside the case if needed.

ModelCRS418-8P-8G-2S+RM
Model nameCRS418-8P-8G-2S+RM
NameNET ROUTER/SWITCH 16PORT SFP+/S4188P8G2S+5AXQ2AXQRM MIKROTIK
PictureUrlhttps://static.elko.cloud/ProductImages/6b4ab988-ecad-4a0a-81ba-e185c14aae31.Jpeg
Power sourceAC/PoE
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/6b4ab988-ecad-4a0a-81ba-e185c14aae31.Jpeg
Unit Calculated Volume0.03186
Unit Calculated Weight3.9
Units per Pallet0
Units per Shipping Box2
Vendor Homepagehttps://mikrotik.com/product/crs418_8p_8g_2s_wifi#fndtn-specifications
