NET SWITCH 8PORT 1000M/CW 2150 S6X56A ARUBA BY HPE

NET SWITCH 8PORT 1000M/CW 2150 S6X56A ARUBA BY HPE
достава за 24h
NET SWITCH 8PORT 1000M/CW 2150 S6X56A ARUBA BY HPE
  • Switch type: Managed
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • SFP module slots quantity: 2
  • Switching capacity: 60
Врз основа на 0 коментари. - Напиши коментар
22,932ден.
  • Достапност: Има залиха
  • Бренд: ARUBA BY HPE
  • Шифра: 460996
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: HPE Networking CW 2150 8p 10M/100M/1G 2p SFP 1G 2p SFP+ 1G/10G Switch. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Switching optical modules type: Gigabit Ethernet. Installed SFP modules quantity: 2, Installed SFP+ modules quantity: 2, Console port: RJ-45/USB Type-C. Switching capacity: 60 Gbit/s
  • Vendor Homepage: https://www.hpe.com/
  • Name: NET SWITCH 8PORT 1000M/CW 2150 S6X56A ARUBA BY HPE
  • Category Code: SWI
  • Model name: Networking CW 2150 8p 10M/100M/1G 2p SFP 1G 2p SFP+ 1G/10G Switch
  • Switch type: Managed
  • Web-based management: Yes
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Gigabit Ethernet (copper) ports quantity: 8
  • Installed SFP modules quantity: 2
  • Installed SFP+ modules quantity: 2
  • SFP module slots quantity: 2
  • SFP+ module slots quantity: 2
  • USB Type-C ports quantity: 1
  • Number of management ports: 2
  • Fiber ports quantity: 4
  • Console port: RJ-45/USB Type-C
  • 10G support: Yes
  • Cable types supported: Fiber
  • Switching optical modules type: Gigabit Ethernet
  • Switching capacity: 60
  • Throughput: 44
  • Throughput: 60
  • Forwarding rate: 44
  • Latency (1 Gbps): 5
  • Latency (10 Gbps): 3
  • Security algorithms: SNMP
  • Management protocols: Web GUI; CLI; SmartMC; IMC; AirWave; REST API; SNMP
  • Supported network protocols: SNMP, REST API
  • Stackable: Yes
  • Number of fans: 0
  • Physical stacking (units): 9
  • Built-in processor: Yes
  • Processor manufacturer: ARM
  • Processor frequency: 1200
  • Memory type: SDRAM
  • Internal memory: 512
  • Flash memory: 512
  • Fanless: Yes
  • Power source: AC
  • Power supply included: Yes
  • Number of power supply units: 1
  • AC input voltage: 100 - 240
  • AC input frequency: 47/63
  • Input voltage: 100 - 240
  • Power consumption (typical): 8
  • Power consumption (max): 16
  • Power consumption note: Idle: 5W Typical: 8W Full load: 16W
  • Power supply note: Fixed, 90-264V, single AC
  • Latency: 1 GE: < 5µs 10 GE: < 3µs (64-byte packets)
  • Dimensions (W x D x H) (imperial): 10.63 x 13.86 x 3.46
  • I/O ports: 8 x 10/100/1000BASE-T ports 2 x 1000BASE-X SFP ports 2 x 1/10GBASE-X SFP+ ports 1 x RJ-45 console, 1 x USB Type-C console, 1 x USB and 1 x OOBM management
  • Memory and processor: CPU: Dual-core Arm at 1.2 GHz Flash: 512 MB SDRAM: 1 GB
  • Performance management: Web GUI Command Line Interface (CLI) Smart Management Center (SmartMC) HPE Intelligence Management Center (IMC) HPE Networking Management Software (AirWave) REST API SNMP
  • Weight (imperial): 3.968
  • Operating temperature (T-T): -5 - 50
  • Heat dissipation: 55
  • Width: 270
  • Depth: 352
  • Height: 87.9
  • Weight: 1800
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.0128
  • Unit Calculated Weight: 2.2
Specifications
10G supportYes
AC input frequency47/63
AC input voltage100 - 240
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Built-in processorYes
Cable types supportedFiber
Console portRJ-45/USB Type-C
Depth352
Dimensions (W x D x H) (imperial)10.63 x 13.86 x 3.46
FanlessYes
Fiber ports quantity4
Flash memory512
Gigabit Ethernet (copper) ports quantity8
Heat dissipation55
Height87.9
I/O ports8 x 10/100/1000BASE-T ports 2 x 1000BASE-X SFP ports 2 x 1/10GBASE-X SFP+ ports 1 x RJ-45 console, 1 x USB Type-C console, 1 x USB and 1 x OOBM management
Input voltage100 - 240
Installed SFP modules quantity2
Installed SFP+ modules quantity2
Internal memory512
Latency1 GE: < 5µs 10 GE: < 3µs (64-byte packets)
Latency (1 Gbps)5
Latency (10 Gbps)3
Management protocolsWeb GUI; CLI; SmartMC; IMC; AirWave; REST API; SNMP
Memory and processorCPU: Dual-core Arm at 1.2 GHz Flash: 512 MB SDRAM: 1 GB
Memory typeSDRAM
Number of fans0
Number of management ports2
Number of power supply units1
Operating temperature (T-T)-5 - 50
Performance managementWeb GUI Command Line Interface (CLI) Smart Management Center (SmartMC) HPE Intelligence Management Center (IMC) HPE Networking Management Software (AirWave) REST API SNMP
Physical stacking (units)9
Power consumption (max)16
Power consumption (typical)8
Power consumption noteIdle: 5W Typical: 8W Full load: 16W
Power supply includedYes
Power supply noteFixed, 90-264V, single AC
Processor frequency1200
Processor manufacturerARM
Security algorithmsSNMP
SFP module slots quantity2
SFP+ module slots quantity2
StackableYes
SummaryHPE Networking CW 2150 8p 10M/100M/1G 2p SFP 1G 2p SFP+ 1G/10G Switch. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Switching optical modules type: Gigabit Ethernet. Installed SFP modules quantity: 2, Installed SFP+ modules quantity: 2, Console port: RJ-45/USB Type-C. Switching capacity: 60 Gbit/s
Supported network protocolsSNMP, REST API
Switching optical modules typeGigabit Ethernet
Throughput60
USB Type-C ports quantity1
Web-based managementYes
Weight1800
Weight (imperial)3.968
Width270
Specs
Category CodeSWI
Description

HPE Networking CW 2150 Switch Series empowers your business with reliable, high-performance networking tailored for small and medium-sized businesses and branch offices. These fully managed, stackable Layer 3 switches deliver enterprise-grade features without the complexity or high cost. With CW 2150 series, you get seamless management, robust security, and flexibility to scale as your needs grow. Designed for today’s evolving networks, these switches provide affordable excellence—enabling you to connect and protect your business with confidence. Upgrade to the CW 2150 series and experience secure, simple, and powerful networking for your organization.

What is new supporting point:
Enterprise-class, fully managed, stackable Layer 3 switch series with 8‑, 16‑, 24‑, and 48‑port Class 4 PoE and non‑PoE models, four 1G/10G SFP+ uplinks, and up to 770W of Class 4 PoE
Managed by Web GUI, CLI, Smart Management Center (SmartMC) web dashboard, HPE Intelligent Management Center (IMC), SNMP, and REST APIs
Up to 176 Gbps in nonblocking bandwidth, 130 Mpps in forwarding, and up to 9‑switch IRF stack
Flexible connectivity options with four 1G/10G SFP+ uplinks in the 16‑, 24‑, and 48‑port models and two 1G SFP and two 1G/10G SFP+ uplinks in the 8‑port model
Advanced Quality of Service (QoS), IPv6, and dynamic L3 protocols (RIP and OSPF) for reliable connectivity
Fanless design in the 8‑port and 24‑/48‑port non‑PoE models. Supports IEEE 802.3az standard for Energy Efficient Ethernet (EEE)

Forwarding rate44
Model nameNetworking CW 2150 8p 10M/100M/1G 2p SFP 1G 2p SFP+ 1G/10G Switch
NameNET SWITCH 8PORT 1000M/CW 2150 S6X56A ARUBA BY HPE
PictureUrlhttps://static.elko.cloud/ProductImages/4791ddcf-654a-42a9-9112-73bb5a8d959c.Jpeg
Power sourceAC
Switch typeManaged
Switching capacity60
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/4791ddcf-654a-42a9-9112-73bb5a8d959c.Jpeg
Unit Calculated Volume0.0128
Unit Calculated Weight2.2
Units per Shipping Box1
Vendor Homepagehttps://www.hpe.com/
