RUTM08

RUTM08
Нов модел
RUTM08
  • Ethernet LAN data rates: 10/100/1000
  • Ethernet LAN (RJ-45) ports: 4
  • Internal memory: 256
Врз основа на 0 коментари. - Напиши коментар
6,691ден.
  • Достапност: Има залиха
  • Бренд: TELTONIKA
  • Шифра: 423884
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Teltonika RUTM08. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u, Ethernet interface type: Gigabit Ethernet, Cabling technology: 10/100/1000Base-T(X). Routing protocols: BGP, EIGRP, NHRP, OSPFv2, RIP-1, RIP-2, VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets, Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE,.... Security algorithms: 128-bit AES, 192-bit AES, 256-bit AES, AES, Firewall security: Port forward, traffic rules, custom rules, Authentication method: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & login attempts.... Processor manufacturer: MediaTek, Processor model: MIPS 1004Kc, Processor frequency: 880 MHz. Product colour: Black
  • Vendor Homepage: https://teltonika-networks.com/products/routers/rutm08
  • Name: NET ROUTER 10/100/1000M 4PORT/RUTM08 TELTONIKA
  • Category Code: ROU
  • Model: RUTM08
  • Ethernet WAN: Yes
  • SIM card slot: Yes
  • Networking standards: IEEE 802.3/IEEE 802.3az/IEEE 802.3u
  • Ethernet interface type: Gigabit Ethernet
  • Cabling technology: 10/100/1000Base-T(X)
  • Ethernet LAN data rates: 10/100/1000
  • Static route: Yes
  • VLAN support: Yes
  • Traffic control: Yes
  • Port forwarding: Yes
  • Auto MDI/MDI-X: Yes
  • Web-based management: Yes
  • Quality of Service (QoS) support: Yes
  • Universal Plug and Play (UPnP): Yes
  • Wake-on-LAN ready: Yes
  • Reset button: Yes
  • Firmware upgradeable: Yes
  • Ethernet LAN (RJ-45) ports: 4
  • Gigabit Ethernet (copper) ports quantity: 4
  • WAN/Ethernet LAN ports quantity: 3
  • WAN ports quantity: 1
  • USB ports quantity: 1
  • USB version: 2.0
  • DMZ support: Yes
  • Routing protocols: BGP/EIGRP/NHRP/OSPFv2/RIP-1/RIP-2
  • VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
  • DHCP client: Yes
  • DHCP server: Yes
  • Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)
  • Security algorithms: 128-bit AES/192-bit AES/256-bit AES/AES
  • Firewall: Yes
  • Firewall security: Port forward, traffic rules, custom rules
  • Authentication method: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & login attempts block, time-based login blocking, built-in random password generator
  • MAC address filtering: Yes
  • IP address filtering: Yes
  • ARP attack prevention: Yes
  • ICMP attack prevention: Yes
  • Network address translation (NAT): Yes
  • Built-in processor: Yes
  • Processor manufacturer: MediaTek
  • Processor model: MIPS 1004Kc
  • Processor frequency: 880
  • Storage media: Flash
  • Flash memory: 256
  • Internal memory: 256
  • Internal memory type: DDR3
  • Operating system installed: RutOS
  • Product colour: Black
  • LED indicators: Yes
  • Power consumption (typical): 3.9
  • Power consumption (max): 12.3
  • Power source type: DC
  • Power plug type: Type E
  • Operating temperature (T-T): -40 - 75
  • Operating relative humidity (H-H): 10 - 90
  • Width: 115
  • Depth: 95.1
  • Height: 44.2
  • Weight: 460
  • Units per Pallet: 0
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.001837
  • Unit Calculated Weight: 0.5
Specifications
ARP attack preventionYes
Authentication methodPre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & login attempts block, time-based login blocking, built-in random password generator
Auto MDI/MDI-XYes
Built-in processorYes
Cabling technology10/100/1000Base-T(X)
Depth95.1
DHCP clientYes
DHCP serverYes
DMZ supportYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN (RJ-45) ports4
Ethernet LAN data rates10/100/1000
Ethernet WANYes
FirewallYes
Firewall securityPort forward, traffic rules, custom rules
Firmware upgradeableYes
Flash memory256
Gigabit Ethernet (copper) ports quantity4
Height44.2
ICMP attack preventionYes
Internal memory256
Internal memory typeDDR3
IP address filteringYes
LED indicatorsYes
MAC address filteringYes
Network address translation (NAT)Yes
Networking standardsIEEE 802.3/IEEE 802.3az/IEEE 802.3u
Operating relative humidity (H-H)10 - 90
Operating system installedRutOS
Operating temperature (T-T)-40 - 75
Port forwardingYes
Power consumption (max)12.3
Power consumption (typical)3.9
Power plug typeType E
Power source typeDC
Processor frequency880
Processor manufacturerMediaTek
Processor modelMIPS 1004Kc
Product colourBlack
Quality of Service (QoS) supportYes
Reset buttonYes
Routing protocolsBGP/EIGRP/NHRP/OSPFv2/RIP-1/RIP-2
Security algorithms128-bit AES/192-bit AES/256-bit AES/AES
SIM card slotYes
Static routeYes
Storage mediaFlash
SummaryTeltonika RUTM08. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u, Ethernet interface type: Gigabit Ethernet, Cabling technology: 10/100/1000Base-T(X). Routing protocols: BGP, EIGRP, NHRP, OSPFv2, RIP-1, RIP-2, VoIP protocols: H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets, Supported network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE,.... Security algorithms: 128-bit AES, 192-bit AES, 256-bit AES, AES, Firewall security: Port forward, traffic rules, custom rules, Authentication method: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & login attempts.... Processor manufacturer: MediaTek, Processor model: MIPS 1004Kc, Processor frequency: 880 MHz. Product colour: Black
Supported network protocolsTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL)
Traffic controlYes
Universal Plug and Play (UPnP)Yes
USB ports quantity1
USB version2.0
VLAN supportYes
VoIP protocolsH.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Wake-on-LAN readyYes
WAN ports quantity1
WAN/Ethernet LAN ports quantity3
Web-based managementYes
Weight460
Width115
Specs
Category CodeROU
Description

RUTM08
INDUSTRIAL WIRED ROUTER
The RUTM08 is an industrial wired router designed for establishing reliable cable connections across a broad range of industrial applications. The router has four Gigabit RJ45 ports, which enable rapid network and data transmission between connected endpoints. The RUTM08 can support up to 128 tag/port-based VLANs for enhanced network flexibility as well as multiple VPNs and M2M communication protocols, which are particularly relevant in industrial environments.

- INTERFACES
4 x Gigabit RJ45 ports with up to 128 tag/port-based VLANs supported
- VPN
Numerous VPN Protocols supported, including Tailscale, OpenVPN, IPsec, ZeroTier, and more
- M2M PROTOCOLS
Multiple industrial protocols supported, including MQTT, Modbus, DNP3, DLMS
- RMS
For remote management, access & VPN services

  • 4 x Gigabit RJ45 ports with up to 128 tag/port-based VLANs supported
  • Numerous VPN Protocols supported, including Tailscale, OpenVPN, IPsec, ZeroTier, and more
  • Multiple industrial protocols supported, including MQTT, Modbus, DNP3, DLMS
  • For remote management, access & VPN services

ModelRUTM08
NameNET ROUTER 10/100/1000M 4PORT/RUTM08 TELTONIKA
PictureUrlhttps://static.elko.cloud/ProductImages/f3c0dbba-6d80-4d7b-b9d6-12d76634a58e.Jpeg
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/f3c0dbba-6d80-4d7b-b9d6-12d76634a58e.Jpeg
Unit Calculated Volume0.001837
Unit Calculated Weight0.5
Units per Pallet0
Units per Shipping Box1
Vendor Homepagehttps://teltonika-networks.com/products/routers/rutm08
