- Switch type: Managed
- Switch layer: L2+
- Basic switching RJ-45 Ethernet ports quantity: 24
- Switching capacity: 128
- Достапност: Има залиха
- Бренд: ARUBA BY HPE
- Шифра: 431635
- Гарантен рок: 12 месеци
- Достава: 13-16 дена
Technical Specifications
- Summary: HPE Networking Instant On Switch 24p Gigabit 4p SFP+ 1930. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Rack mounting, Form factor: 1U
- Vendor Homepage: https://buy.hpe.com/uk/en/networking/switches/fixed-port-web-managed-ethernet-switches/aruba-1900-switch-products/aruba-instant-on-1930-switch-series/aruba-instant-on-1930-24g-4sfp-sfp-switch/p/JL682A
- Name: NET SWITCH 24PORT 1000M 4SFP+/ION 1930 JL682A ARUBA BY HPE
- Category Code: SWI
- Model name: JL682A
- Switch type: Managed
- Switch layer: L2+
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Basic switching RJ-45 Ethernet ports quantity: 24
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity: 4
- Networking standards: IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u/IEEE 802.3x
- 10G support: Yes
- Port mirroring: Yes
- Full duplex: Yes
- Auto MDI/MDI-X: Yes
- Auto-sensing: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Rate limiting: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Number of VLANs: 256
- Switching capacity: 128
- Throughput: 95.23
- MAC address table: 16000
- Latency (10-100 Mbps): 4.7
- Latency (1 Gbps): 2.4
- Latency (10 Gbps): 1.3
- Jumbo frames support: Yes
- Packet buffer memory: 1.5
- IGMP snooping: Yes
- SSH/SSL support: Yes
- Rack mounting: Yes
- Form factor: 1U
- Product colour: White
- Processor model: ARM Cortex-A9
- Processor frequency: 800
- Memory type: SDRAM
- Internal memory: 512
- Flash memory: 256
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240
- AC input frequency: 50 - 60
- Power consumption (max): 22.6
- Operating temperature (T-T): 0 - 40
- Storage temperature (T-T): -40 - 70
- Operating relative humidity (H-H): 15 - 95
- Storage relative humidity (H-H): 15 - 95
- Width: 442.5
- Depth: 221.5
- Height: 43.9
- Weight: 2410
- Harmonized System (HS) code: 85176990
- Units per Shipping Box: 1
- Unit Calculated Volume: 0.0222
- Unit Calculated Weight: 4
| Specifications | |
| 10G support | Yes |
| AC input frequency | 50 - 60 |
| AC input voltage | 100 - 240 |
| Auto MDI/MDI-X | Yes |
| Auto-sensing | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Depth | 221.5 |
| Flash memory | 256 |
| Flow control support | Yes |
| Form factor | 1U |
| Full duplex | Yes |
| Harmonized System (HS) code | 85176990 |
| Height | 43.9 |
| IGMP snooping | Yes |
| Internal memory | 512 |
| Jumbo frames support | Yes |
| Latency (1 Gbps) | 2.4 |
| Latency (10 Gbps) | 1.3 |
| Latency (10-100 Mbps) | 4.7 |
| Link aggregation | Yes |
| MAC address table | 16000 |
| Memory type | SDRAM |
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u/IEEE 802.3x |
| Number of VLANs | 256 |
| Operating relative humidity (H-H) | 15 - 95 |
| Operating temperature (T-T) | 0 - 40 |
| Packet buffer memory | 1.5 |
| Port mirroring | Yes |
| Power consumption (max) | 22.6 |
| Power supply included | Yes |
| Processor frequency | 800 |
| Processor model | ARM Cortex-A9 |
| Product colour | White |
| Quality of Service (QoS) support | Yes |
| Rack mounting | Yes |
| Rate limiting | Yes |
| SFP+ module slots quantity | 4 |
| Spanning tree protocol | Yes |
| SSH/SSL support | Yes |
| Storage relative humidity (H-H) | 15 - 95 |
| Storage temperature (T-T) | -40 - 70 |
| Summary | HPE Networking Instant On Switch 24p Gigabit 4p SFP+ 1930. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Rack mounting, Form factor: 1U |
| Switch layer | L2+ |
| Throughput | 95.23 |
| VLAN support | Yes |
| Web-based management | Yes |
| Weight | 2410 |
| Width | 442.5 |
| Specs | |
| Category Code | SWI |
| Description | The Aruba Instant On 1930 switch series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The Aruba Instant On 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1G SFP slots on 8-port model and 1G/10G SFP+ slots on 24-/48G models for fiber connectivity. |
| Model name | JL682A |
| Name | NET SWITCH 24PORT 1000M 4SFP+/ION 1930 JL682A ARUBA BY HPE |
| PictureUrl | https://static.elko.cloud/ProductImages/d3802d8a-5da5-479c-8cb0-dfec59ec24ca.Jpeg |
| Power source | AC |
| Switch type | Managed |
| Switching capacity | 128 |
| thumbnailImagePath | https://static.elko.cloud/ProductImagesThumbs/d3802d8a-5da5-479c-8cb0-dfec59ec24ca.Jpeg |
| Unit Calculated Volume | 0.0222 |
| Unit Calculated Weight | 4 |
| Units per Shipping Box | 1 |
| Vendor Homepage | https://buy.hpe.com/uk/en/networking/switches/fixed-port-web-managed-ethernet-switches/aruba-1900-switch-products/aruba-instant-on-1930-switch-series/aruba-instant-on-1930-24g-4sfp-sfp-switch/p/JL682A |
