NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS

NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS
NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS
  • Switch type: Managed
  • Basic switching RJ-45 Ethernet ports quantity: 4
  • Switching capacity: 16
Врз основа на 0 коментари. - Напиши коментар
52,918ден.
  • Достапност:
  • Бренд: AXIS
  • Шифра: 262974
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Axis 01633-001. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4, Console port: RJ-45. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1x. DC input voltage: 54 - 57 V. Power connector: DC-in jack. Power over Ethernet (PoE)
  • Vendor Homepage: https://www.axis.com/
  • Name: NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS
  • Category Code: SWI
  • Switch type: Managed
  • Basic switching RJ-45 Ethernet ports quantity: 4
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Fiber optic connector: SFP
  • Console port: RJ-45
  • Power connector: DC-in jack
  • Networking standards: IEEE 802.1Q/IEEE 802.1x
  • VLAN support: Yes
  • Switching capacity: 16
  • Throughput: 11.9
  • MAC address table: 8000
  • Jumbo frames support: Yes
  • Jumbo frames: 9216
  • Authentication type: RADIUS
  • Password protection: Yes
  • Security algorithms: HTTPS/SNMP/SNMPv3
  • Product colour: Black
  • Housing material: Aluminium
  • DC input voltage: 54 - 57
  • Surge protection: Yes
  • Power over Ethernet (PoE): Yes
  • Power over Ethernet (PoE) ports quantity: 4
  • Power over Ethernet (PoE) power per port: 60
  • Total Power over Ethernet (PoE) budget: 240
  • Operating temperature (T-T): -40 - 75
  • Storage temperature (T-T): -40 - 85
  • Operating relative humidity (H-H): 5 - 95
  • Width: 62
  • Depth: 130
  • Height: 135
  • Weight: 600
  • Quick start guide: Yes
  • Mounting brackets included: Yes
  • Certification: EN 55032, EN 55024, FCC, ICES-003, VCCI, RCM AS/NZS CISPR 32, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 IEC 62236-4, IEC/EN/UL 60950-1, IEC 60068-2-6, IEC 60068-2-27, 60068-2-31, NEMA TS-2-2003
  • Harmonized System (HS) code: 85176990
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.004641
  • Unit Calculated Weight: 1.06
Specifications
Authentication typeRADIUS
Basic switching RJ-45 Ethernet ports quantity4
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
CertificationEN 55032, EN 55024, FCC, ICES-003, VCCI, RCM AS/NZS CISPR 32, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 IEC 62236-4, IEC/EN/UL 60950-1, IEC 60068-2-6, IEC 60068-2-27, 60068-2-31, NEMA TS-2-2003
Console portRJ-45
DC input voltage54 - 57
Depth130
Fiber optic connectorSFP
Harmonized System (HS) code85176990
Height135
Housing materialAluminium
Jumbo frames9216
Jumbo frames supportYes
MAC address table8000
Mounting brackets includedYes
Networking standardsIEEE 802.1Q/IEEE 802.1x
Operating relative humidity (H-H)5 - 95
Operating temperature (T-T)-40 - 75
Password protectionYes
Power connectorDC-in jack
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity4
Power over Ethernet (PoE) power per port60
Product colourBlack
Quick start guideYes
Security algorithmsHTTPS/SNMP/SNMPv3
Storage temperature (T-T)-40 - 85
SummaryAxis 01633-001. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4, Console port: RJ-45. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1x. DC input voltage: 54 - 57 V. Power connector: DC-in jack. Power over Ethernet (PoE)
Throughput11.9
Total Power over Ethernet (PoE) budget240
VLAN supportYes
Weight600
Width62
Specs
Category CodeSWI
Description

AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE Gigabit switch. In addition, the switch is equipped with two RJ45 and two SFP data ports that allows for extra devices to be connected. The switch uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series. The ruggedized switch is perfect for challenging environments when mounted inside a surveillance cabinet. It is designed to withstand shock, vibrations and temperatures from -40 °C to 75 °C (-40 °F to 167 °F), making it perfect for high demanding installations such as alongside highways and tunnels.

  • 60 W per port, 240 W power budget; Compliant with High PoE 60 W; Dual DC power redundancy; High availability with Rapid Ring; NEMA TS-2 compliant

NameNET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS
PictureUrlhttps://static.elko.cloud/ProductImages/e435b5a5-9798-46bc-8fd6-f45abd4f39b5.Jpeg
Surge protectionYes
Switch typeManaged
Switching capacity16
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/e435b5a5-9798-46bc-8fd6-f45abd4f39b5.Jpeg
Unit Calculated Volume0.004641
Unit Calculated Weight1.06
Units per Shipping Box1
Vendor Homepagehttps://www.axis.com/
