UBIQUITI Ultra 60W

Technical Specifications

• Summary: Ubiquiti Ultra 60W. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Switching capacity: 16 Gbit/s. DC input voltage: 44 - 57 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
• Vendor Homepage: https://store.ui.com/us/en/collections/unifi-switching-utility-poe/products/usw-ultra-60w
• Name: NET SWITCH 8PORT GBE POE+/USW-ULTRA-60W UBIQUITI
• Category Code: SWI
• Model: UBIQUITI Ultra 60W
• Series: Ultra
• Model name: Ultra 60W
• Switch type: Managed
• Switch layer: L2
• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Power connector: DC-in jack
• Port mirroring: Yes
• Broadcast storm control: Yes
• Flow control support: Yes
• Rate limiting: Yes
• Switching capacity: 16
• Throughput: 8
• Jumbo frames support: Yes
• Multicast support: Yes
• Product colour: White
• Housing material: Polycarbonate (PC)
• Reset button: Yes
• LED indicators: Activity/Link/PoE/Status
• Wall mountable: Yes
• Power source: DC/PoE
• Power supply included: Yes
• Number of power supply units: 1
• DC input voltage: 44 - 57
• Input current: 1.1
• Power consumption (max): 9
• Power over Ethernet (PoE): Yes
• Power over Ethernet (PoE) ports quantity: 7
• Power over Ethernet plus (PoE+) ports quantity: 7
• Power over Ethernet 4PPoE (PoE++) ports quantity: 1
• Power over Ethernet (PoE) power per port: 30
• Total Power over Ethernet (PoE) budget: 42
• Operating temperature (T-T): -20 - 45
• Operating relative humidity (H-H): 10 - 90
• Width: 203
• Depth: 76
• Height: 33
• Weight: 320
• Cables included: Power
• Manual: Yes
• Compliance certificates: CE/Federal Communications Commission (FCC)/Industry Canada (IC)
• Units per Shipping Box: 6
• Unit Calculated Volume: 0.004703
• Unit Calculated Weight: 1.1
