NET CAMERA P1467-LE/02341-001 AXIS

Technical Specifications

• Summary: Axis 02341-001. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.13 lx, Camera shutter speed: 1/50000 - 1/5 s. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Focal length range: 2.8 - 8 mm
• Vendor Homepage: https://www.axis.com/products/axis-p1467-le#part-numbers
• Name: NET CAMERA P1467-LE/02341-001 AXIS
• Category Code: FNC
• Model: P1467-LE
• Form factor: Bullet
• Mounting type: Ceiling/wall
• Product colour: White
• Housing material: Aluminium/Polycarbonate (PC)
• International Protection (IP) code: IP66, IP67
• IK code: IK10
• Weatherproof: Yes
• Type: IP security camera
• Connectivity technology: Wired
• Placement supported: Indoor & outdoor
• PTZ modes: Digital PTZ
• Wide Dynamic Range (WDR): Yes
• Day/night mode: Yes
• Infrared (IR) cut-off filter: Yes
• Languages support: English/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese
• Number of languages: 12
• Certification: EN 55032 Class A, EN 50121-4, IEC 62236-4, EN 55035, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A
• Minimum illumination: 0.13
• Camera shutter speed: 1/50000 - 1/5
• Number of sensors: 1
• Optical sensor size: 1/2.7
• Progressive scan: Yes
• Sensor type: CMOS
• Zoom capability: Yes
• Number of lenses: 1
• Focal length range: 2.8 - 8
• Night vision: Yes
• Night vision distance: 40
• LED type: IR
• Infra-red wavelength: 850
• Maximum resolution: 2592 x 1944
• Total megapixels: 5
• Video compression formats: H.264/H.265
• Supported graphics resolutions: 1280 x 720 (HD 720)
• Supported video modes: 720p
• Video recording: Yes
• Frame rate: 30
• Video streaming: Yes
• Bit rate: Configurable bit rate
• Flip & mirror: Yes
• Privacy masking: Yes
• Text caption overlay: Yes
• Audio formats supported: AAC-LC/ADPCM/G.711/G.726/LPCM/OPUS/PCM
• Audio detection: Yes
• Ethernet LAN: Yes
• Networking standards: IEEE 802.1x/IEEE 802.3af/IEEE 802.3at
• Supported network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SOCKS, SS
• Quality of Service (QoS) support: Yes
• Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC/SD
• Flash memory: 8000
• Internal memory: 2000
• Ethernet LAN (RJ-45) ports: 1
• Microphone in: Yes
• Terminal block port: Yes
• Password protection: Yes
• Active tampering alarm: Yes
• Alert notification type: E-mail,Text alert message
• Digest authentication: Yes
• HTTPS encryption: Yes
• IP address filtering: Yes
• Pixel counter: Yes
• Security algorithms: 256-bit AES-XTS/EAP-TLS
• Video motion detection: Yes
• Power source type: PoE
• Power consumption (typical): 5.8
• Power consumption (max): 12.9
• Operating temperature (T-T): -40 - 60
• Storage temperature (T-T): -40 - 65
• Operating relative humidity (H-H): 10 - 100
• Storage relative humidity (H-H): 5 - 95
• Windows operating systems supported: Yes
• Width: 280
• Depth: 280
• Diameter: 132
• Weight: 1200
• Number of cameras: 1
• Mounting brackets included: Yes
• Drilling template included: Yes
• Manual: Yes
• Doesnt contain: BFR/PVC
• Units per Pallet: 0
• Units per Shipping Box: 6
• Unit Calculated Volume: 0.00721
• Unit Calculated Weight: 1.6
