NET SWITCH 24PORT 10/100/1000/DGS-1100-24PV2 D-LINK

NET SWITCH 24PORT 10/100/1000/DGS-1100-24PV2 D-LINK
NET SWITCH 24PORT 10/100/1000/DGS-1100-24PV2 D-LINK
  • Switch type: Managed
  • Switch layer: L2
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Switching capacity: 48
Врз основа на 0 коментари. - Напиши коментар
22,271ден.
  • Достапност: Нема на залиха
  • Шифра: 331756
  • Гарантен рок: 12 месеци
  • Рок на испорака: 13-16 дена
D-LINK
Во кошничка
Листа на желби Спореди
Сподели

Technical Specifications

  • Summary: D-Link 24-Port PoE Gigabit Smart Managed Switch. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE). Rack mounting
  • Vendor Homepage: https://www.dlink.com/en/products/dgs-1100-24pv2-24-port-gigabit-poe-smart-managed-switch
  • Name: NET SWITCH 24PORT 10/100/1000/DGS-1100-24PV2 D-LINK
  • Category Code: SWI
  • Model name: DGS-1100-24PV2
  • Switch type: Managed
  • Switch layer: L2
  • Quality of Service (QoS) support: Yes
  • Web-based management: Yes
  • System event log: Yes
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Networking standards: IEEE 802.1AX/IEEE 802.1D/IEEE 802.1p/IEEE 802.1Q/IEEE 802.1w/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
  • Copper ethernet cabling technology: 1000BASE-T/10BASE-T/10BASE-TX
  • Port mirroring: Yes
  • Full duplex: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • Broadcast storm control: Yes
  • Flow control support: Yes
  • Head-of-line (HOL) blocking: Yes
  • Link aggregation: Yes
  • Rate limiting: Yes
  • Spanning tree protocol: Yes
  • VLAN support: Yes
  • Virtual LAN features: Port-based VLAN/Voice VLAN
  • Number of VLANs: 128
  • Switching capacity: 48
  • Forwarding rate: 35.71
  • MAC address table: 8000
  • Store-and-forward: Yes
  • Number of queues: 4
  • Jumbo frames support: Yes
  • Jumbo frames: 9216
  • Packet buffer memory: 4.1
  • DHCP features: DHCP client
  • IGMP snooping: Yes
  • Queue scheduling algorithms: SPQ/Weighted Round Robin (WRR)
  • Security algorithms: SNMP/SSL/TLS
  • Multicast support: Yes
  • Rack mounting: Yes
  • Product colour: Black
  • LED indicators: Yes
  • Built-in processor: Yes
  • Processor frequency: 125
  • Memory type: DRAM
  • Flash memory: 16
  • Noise level: 0
  • Fanless: Yes
  • Mean time between failures (MTBF): 255003
  • AC input voltage: 100 - 240
  • Power consumption (max): 19.5
  • Power over Ethernet (PoE): Yes
  • Power over Ethernet plus (PoE+) ports quantity: 12
  • Power over Ethernet (PoE) power per port: 30
  • Total Power over Ethernet (PoE) budget: 100
  • Operating temperature (T-T): -5 - 50
  • Storage temperature (T-T): -40 - 70
  • Operating relative humidity (H-H): 0 - 95
  • Storage relative humidity (H-H): 0 - 95
  • Operating altitude: 0 - 2000
  • Heat dissipation: 107.5
  • Width: 280
  • Depth: 230
  • Height: 44
  • Weight: 2200
  • Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
  • Harmonized System (HS) code: 85176990
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.0126
  • Unit Calculated Weight: 3
