NET CAMERA Q1800-LE/03107-001 AXIS

Technical Specifications

• Summary: Axis Q1800-LE. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.06 lx, Angle of rotation: 270°, Horizontal field of view (thermal module): 38 - 2.3°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Sensor type (panoramic camera): CMOS, Signal-to-Noise Ratio (SNR) (panoramic camera): 55 dB
• Vendor Homepage: https://www.axis.com/products/axis-q1800-le
• Name: NET CAMERA Q1800-LE/03107-001 AXIS
• Category Code: FNC
• Model: 03107-001
• Form factor: Bullet
• Mounting type: Wall
• Product colour: Black
• Housing material: Aluminium/Glass
• Protection features: Impact resistant/Vandal proof/Weather resistant
• International Protection (IP) code: IP66
• IK code: IK08, IK10
• Type: IP security camera
• Connectivity technology: Wired
• Placement supported: Outdoor
• PTZ control: Yes
• PTZ modes: Digital PTZ
• Preset points: Yes
• Wide Dynamic Range (WDR): Yes
• Day/night mode: Yes
• Infrared (IR) cut-off filter: Yes
• Certification: UL/cUL, BIS, UKCA, CE, KC, VCCI, RCM
• Minimum illumination: 0.06
• Angle of rotation: 270
• Horizontal field of view (thermal module): 38 - 2.3
• Lens viewing angle, horizontal: 22 - 1.3
• Tilt angle range: 0 - 90
• Pan range: -180 - 180
• Camera pixel size: 2.9
• Camera shutter speed: 1/111000 - 2
• Sensor type (panoramic camera): CMOS
• Signal-to-Noise Ratio (SNR) (panoramic camera): 55
• Number of sensors: 1
• Optical sensor size: 1/2.8
• Sensor type: CMOS
• Number of lenses: 1
• Focal length range: 7 - 138
• Auto focus: Yes
• Identify distance: 1.2
• Closest focusing distance: 1.2
• Detect distance (tele): 1884.2
• Detect distance (wide): 96.7
• Identify distance (tele): 188.4
• Identify distance (wide): 9.7
• Observe distance (tele): 747.7
• Observe distance (wide): 38.4
• Recognize distance (tele): 376.8
• Recognize distance (wide): 19.3
• Night vision: Yes
• Night vision distance: 100
• B/W night vision distance: 50
• LED type: IR
• Infra-red wavelength: 850
• Maximum resolution: 1920 x 1080
• Video formats supported: AVC/H.264/H.265/M-JPEG
• Supported graphics resolutions: 1400 x 1050 (SXGA+)/160 x 120/1920 x 1080 (HD 1080)/320 x 180
• Supported video modes: 1080p
• Frame rate: 90
• Video streaming: Yes
• Noise reduction: Yes
• Noise reduction technology: 2D noise reduction,3D noise reduction
• Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
• Image quality adjustment: Brightness/Contrast/Saturation/Sharpness
• Image stabilizer: Yes
• Text caption overlay: Yes
• Built-in speaker(s): Yes
• Audio system: 2-way
• Audio formats supported: AAC-LC/ADPCM/LPCM/OPUS/PCM
• Sample rate: 48
• Signal-to-Noise Ratio (SNR): 55
• Audio detection: Yes
• Ethernet LAN: Yes
• Networking standards: IEEE 802.3af/IEEE 802.3at
• Supported network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS3 , HTTP/ 2, TLS3 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SSH
• Streaming method: Multicast
• Card reader integrated: Yes
• Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
• Flash memory: 8192
• Internal memory: 2048
• Ethernet LAN (RJ-45) ports: 1
• Microphone in: Yes
• Terminal block port: Yes
• DC-in jack: Yes
• Password protection: Yes
• Active tampering alarm: Yes
• Digest authentication: Yes
• Intelligent Video Surveillance (IVS) system features: Human detection/Line crossing detection/Moving object/Vehicle detection
• Pixel counter: Yes
• Security algorithms: HTTPS
• Video motion detection: Yes
• Remotely operated: Yes
• Power source type: PoE
• Power consumption (typical): 11
• Power consumption (max): 29
• Operating temperature (T-T): -40 - 60
• Storage temperature (T-T): -40 - 65
• Operating relative humidity (H-H): 10 - 100
• Storage relative humidity (H-H): 5 - 95
• Width: 183
• Depth: 464
• Height: 183
• Weight: 3200
• Compliance certificates: Electromagnetic Compatibility (EMC)/Trade Agreements Act (TAA)
• Number of cameras: 1
• Cables included: LAN (RJ-45)
• Manual: Yes
• Doesnt contain: BFR/CFR
• Units per Shipping Box: 1
• Unit Calculated Volume: 0.02047
• Unit Calculated Weight: 4.04
