NET CAMERA 4K BULLET AI OUTD./WV-S15701-Z3LN I-PRO

NET CAMERA 4K BULLET AI OUTD./WV-S15701-Z3LN I-PRO
NET CAMERA 4K BULLET AI OUTD./WV-S15701-Z3LN I-PRO
  • Connectivity technology: Wired
  • Zoom capability: Yes
  • Maximum resolution: 3840 x 2160
  • Ethernet LAN: Yes
Врз основа на 0 коментари. - Напиши коментар
133,486ден.
  • Достапност:
  • Бренд: I-PRO
  • Шифра: 453999
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: i-PRO WV-S15701-Z3LN. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.13 lx, Tilt angle range: 0 - 100°, Pan range: 180 - 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 30x, Digital zoom: 480x, Focal length range: 4.5 - 135 mm
  • Vendor Homepage: https://i-pro.com/products_and_solutions/apac-en/surveillance/products/wv-s15701-z3ln
  • Name: NET CAMERA 4K BULLET AI OUTD./WV-S15701-Z3LN I-PRO
  • Category Code: FNC
  • Form factor: Bullet
  • Mounting type: Ceiling/wall
  • Product colour: White
  • Housing material: Aluminium/Polycarbonate (PC)
  • Protection features: Corrosion resistant
  • International Protection (IP) code: IP66, IP67
  • IK code: IK10
  • Type: IP security camera
  • Connectivity technology: Wired
  • Placement supported: Outdoor
  • Day/night mode: Yes
  • Alarm input/output: Yes
  • Dynamic range: 132
  • Languages support: English/French/German/Italian/Japanese/Portuguese/Russian/Simplified Chinese/Spanish
  • Number of languages: 9
  • Minimum illumination: 0.13
  • Tilt angle range: 0 - 100
  • Pan range: 180 - 180
  • White balance: ATW/AWC
  • Camera shutter speed: 1/10000 - 16/30
  • Optical sensor size: 1/2.8
  • Sensor type: CMOS
  • Zoom capability: Yes
  • Optical zoom: 30
  • Digital zoom: 480
  • Focal length range: 4.5 - 135
  • Focus: Motorized
  • Maximum aperture number: 4.7
  • Minimum aperture number: 1.8
  • Detect distance (tele): 3519.7
  • Detect distance (wide): 127.1
  • Identify distance (tele): 352
  • Identify distance (wide): 12.7
  • Normal focusing range: 3
  • Observe distance (tele): 1407.9
  • Observe distance (wide): 50.8
  • Recognize distance (tele): 703.9
  • Recognize distance (wide): 25.4
  • Night vision: Yes
  • Night vision distance: 140
  • LED type: IR
  • Maximum resolution: 3840 x 2160
  • Video compression formats: H.264/H.265
  • Frame rate: 30
  • Noise reduction: Yes
  • Back Light Compensation (BLC): Yes
  • Highlight Compensation (HLC): Yes
  • Image quality adjustment: Automatic gain control (AGC)
  • Image stabilizer: Yes
  • Audio system full duplex: Yes
  • Audio formats supported: AAC-LC/G.711/G.726
  • Audio detection: Yes
  • Ethernet LAN: Yes
  • Networking standards: IEEE 802.1x/IEEE 802.3at/IEEE 802.3bt
  • Supported network protocols: IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, LLDP, MQTT IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3,
  • Number of users: 14
  • Streaming method: Multicast/Unicast
  • Card reader integrated: Yes
  • Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
  • Maximum memory card size: 512
  • Ethernet LAN (RJ-45) ports: 1
  • Alert notification type: E-mail
  • Security algorithms: FIPS 140-2
  • Video motion detection: Yes
  • Web browser: Yes
  • Behavior analysis: Scene change detection
  • Power source type: PoE
  • Power consumption: 600
  • Power consumption (typical): 32.4
  • DC output voltage: 12,54
  • DC output current: 1.3
  • Operating temperature (T-T): -40 - 60
  • Storage temperature (T-T): -30 - 60
  • Operating relative humidity (H-H): 10 - 100
  • Mobile operating systems supported: Android/iOS
  • Width: 168
  • Depth: 168
  • Height: 456
  • Weight: 3600
  • Compliance certificates: cUL/Federal Communications Commission (FCC)/National Defense Authorization Act (NDAA)/UL
  • Number of cameras: 1
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.015
  • Unit Calculated Weight: 4
Specifications
Alarm input/outputYes
Alert notification typeE-mail
Audio detectionYes
Audio formats supportedAAC-LC/G.711/G.726
Audio system full duplexYes
Back Light Compensation (BLC)Yes
Behavior analysisScene change detection
Camera shutter speed1/10000 - 16/30
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)/MicroSDHC/MicroSDXC
Compliance certificatescUL/Federal Communications Commission (FCC)/National Defense Authorization Act (NDAA)/UL
Connectivity technologyWired
Day/night modeYes
DC output current1.3
DC output voltage12,54
Depth168
Detect distance (tele)3519.7
Detect distance (wide)127.1
Digital zoom480
Dynamic range132
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Focal length range4.5 - 135
FocusMotorized
Form factorBullet
Frame rate30
Height456
Highlight Compensation (HLC)Yes
Housing materialAluminium/Polycarbonate (PC)
Identify distance (tele)352
Identify distance (wide)12.7
IK codeIK10
Image quality adjustmentAutomatic gain control (AGC)
Image stabilizerYes
International Protection (IP) codeIP66, IP67
Languages supportEnglish/French/German/Italian/Japanese/Portuguese/Russian/Simplified Chinese/Spanish
LED typeIR
Maximum aperture number4.7
Maximum memory card size512
Maximum resolution3840 x 2160
Minimum aperture number1.8
Minimum illumination0.13
Mobile operating systems supportedAndroid/iOS
Mounting typeCeiling/wall
Networking standardsIEEE 802.1x/IEEE 802.3at/IEEE 802.3bt
Night visionYes
Night vision distance140
Noise reductionYes
Normal focusing range3
Number of cameras1
Number of languages9
Number of users14
Observe distance (tele)1407.9
Observe distance (wide)50.8
Operating relative humidity (H-H)10 - 100
Operating temperature (T-T)-40 - 60
Optical sensor size1/2.8
Optical zoom30
Pan range180 - 180
Placement supportedOutdoor
Power consumption (typical)32.4
Power source typePoE
Product colourWhite
Protection featuresCorrosion resistant
Recognize distance (tele)703.9
Recognize distance (wide)25.4
Security algorithmsFIPS 140-2
Sensor typeCMOS
Storage temperature (T-T)-30 - 60
Streaming methodMulticast/Unicast
Summaryi-PRO WV-S15701-Z3LN. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.13 lx, Tilt angle range: 0 - 100°, Pan range: 180 - 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 30x, Digital zoom: 480x, Focal length range: 4.5 - 135 mm
Supported network protocolsIPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, LLDP, MQTT IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3,
Tilt angle range0 - 100
TypeIP security camera
Video compression formatsH.264/H.265
Video motion detectionYes
Web browserYes
Weight3600
White balanceATW/AWC
Width168
Zoom capabilityYes
Specs
Category CodeFNC
Description

4K AI Outdoor IR Bullet Camera (30x zoom)


  • 4K Bullet camera
  • Up to 3 Edge AI analytic apps
  • 30x optical zoom
  • Built-in IR LED (140m/459ft)
  • IP66, IP67, IK10 certified
  • Built-in FIPS 140-2 Level 3 Certified SecureElement (EdgeLock® SE050F NXP® Semiconductors)
  • NDAA Compliant

NameNET CAMERA 4K BULLET AI OUTD./WV-S15701-Z3LN I-PRO
PictureUrlhttps://static.elko.cloud/ProductImages/78375bd6-c157-4dda-a00c-15d9ee7156b9.Jpeg
Power consumption600
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/78375bd6-c157-4dda-a00c-15d9ee7156b9.Jpeg
Unit Calculated Volume0.015
Unit Calculated Weight4
Units per Shipping Box1
Vendor Homepagehttps://i-pro.com/products_and_solutions/apac-en/surveillance/products/wv-s15701-z3ln
