NET CAMERA 5MP BULLET AI OUTD./WV-X22500-V3L I-PRO

NET CAMERA 5MP BULLET AI OUTD./WV-X22500-V3L I-PRO
NET CAMERA 5MP BULLET AI OUTD./WV-X22500-V3L I-PRO
  • Connectivity technology: Wired
  • Zoom capability: Yes
  • Total megapixels: 2
  • Ethernet LAN: Yes
Врз основа на 0 коментари. - Напиши коментар
96,698ден.
  • Достапност: Има залиха
  • Бренд: I-PRO
  • Шифра: 453905
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: i-PRO WV-X22500-V3L. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.005 lx, Tilt angle range: -30 - 85°, Pan range: -194 - 166°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 3.1x, Digital zoom: 9.3x, Focal length range: 2.9 - 9 mm
  • Vendor Homepage: https://i-pro.com/products_and_solutions/us-en/surveillance/products/wv-x22500-v3l
  • Name: NET CAMERA 5MP BULLET AI OUTD./WV-X22500-V3L I-PRO
  • Category Code: FNC
  • Form factor: Dome
  • Mounting type: Ceiling/wall
  • Product colour: White
  • Housing material: Aluminium/Stainless steel
  • Protection features: Vandal proof
  • International Protection (IP) code: IP66, IP67
  • IK code: IK10
  • Fog proof: Yes
  • Type: IP security camera
  • Connectivity technology: Wired
  • Placement supported: Outdoor
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes
  • Alarm input/output: Yes
  • Dynamic range: 144
  • Minimum illumination: 0.005
  • Tilt angle range: -30 - 85
  • Pan range: -194 - 166
  • White balance: ATW/AWC
  • Camera shutter speed: 1/25 - 1/10000
  • Optical sensor size: 1/2.8
  • Sensor type: CMOS
  • Zoom capability: Yes
  • Optical zoom: 3.1
  • Digital zoom: 9.3
  • Focal length range: 2.9 - 9
  • Maximum aperture number: 2.5
  • Minimum aperture number: 1.3
  • Closest focusing distance: 0.3
  • Detect distance (tele): 118.2
  • Detect distance (wide): 25.4
  • Identify distance (tele): 11.8
  • Identify distance (wide): 2.5
  • Observe distance (tele): 47.3
  • Observe distance (wide): 10.2
  • Recognize distance (tele): 23.6
  • Recognize distance (wide): 5.1
  • Night vision: Yes
  • Night vision distance: 70
  • LED type: IR
  • Total megapixels: 2
  • Video compression formats: H.264/H.265
  • Frame rate: 60
  • Video intelligence analytic: Yes
  • Noise reduction: Yes
  • Back Light Compensation (BLC): Yes
  • Highlight Compensation (HLC): Yes
  • Image stabilizer: Yes
  • Privacy masking: Yes
  • Audio detection: Yes
  • Ethernet LAN: Yes
  • Ethernet interface type: Fast Ethernet
  • Supported network protocols: IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, LLDP, MQTT IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3,
  • Number of users: 14
  • Card reader integrated: Yes
  • Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
  • Maximum memory card size: 512
  • Ethernet LAN (RJ-45) ports: 1
  • Microphone in: Yes
  • Active tampering alarm: Yes
  • Intelligent Video Surveillance (IVS) system features: Abnormal sound detection/Face detection/Scene change/Vehicle detection
  • Video motion detection: Yes
  • Web-based management: Yes
  • Web browser: Yes
  • Smartphone/tablet remote support: Yes
  • Power source type: DC,PoE
  • DC output voltage: 12
  • Operating temperature (T-T): -40 - 55
  • Operating relative humidity (H-H): 10 - 100
  • Height: 105
  • Diameter: 154
  • Weight: 1100
  • Number of cameras: 1
  • Units per Pallet: 0
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.00459
  • Unit Calculated Weight: 1.5
Specifications
Active tampering alarmYes
Alarm input/outputYes
Audio detectionYes
Back Light Compensation (BLC)Yes
Camera shutter speed1/25 - 1/10000
Card reader integratedYes
Closest focusing distance0.3
Compatible memory cardsMicroSD (TransFlash)/MicroSDHC/MicroSDXC
Connectivity technologyWired
Day/night modeYes
DC output voltage12
Detect distance (tele)118.2
Detect distance (wide)25.4
Diameter154
Digital zoom9.3
Dynamic range144
Ethernet interface typeFast Ethernet
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Focal length range2.9 - 9
Fog proofYes
Form factorDome
Frame rate60
Height105
Highlight Compensation (HLC)Yes
Housing materialAluminium/Stainless steel
Identify distance (tele)11.8
Identify distance (wide)2.5
IK codeIK10
Image stabilizerYes
Infrared (IR) cut-off filterYes
Intelligent Video Surveillance (IVS) system featuresAbnormal sound detection/Face detection/Scene change/Vehicle detection
International Protection (IP) codeIP66, IP67
LED typeIR
Maximum aperture number2.5
Maximum memory card size512
Microphone inYes
Minimum aperture number1.3
Minimum illumination0.005
Mounting typeCeiling/wall
Night visionYes
Night vision distance70
Noise reductionYes
Number of cameras1
Number of users14
Observe distance (tele)47.3
Observe distance (wide)10.2
Operating relative humidity (H-H)10 - 100
Operating temperature (T-T)-40 - 55
Optical sensor size1/2.8
Optical zoom3.1
Pan range-194 - 166
Placement supportedOutdoor
Power source typeDC,PoE
Privacy maskingYes
Product colourWhite
Protection featuresVandal proof
Recognize distance (tele)23.6
Recognize distance (wide)5.1
Sensor typeCMOS
Smartphone/tablet remote supportYes
Summaryi-PRO WV-X22500-V3L. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.005 lx, Tilt angle range: -30 - 85°, Pan range: -194 - 166°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Optical zoom: 3.1x, Digital zoom: 9.3x, Focal length range: 2.9 - 9 mm
Supported network protocolsIPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, FTP, SFTP, LLDP, MQTT IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3,
Tilt angle range-30 - 85
Total megapixels2
TypeIP security camera
Video compression formatsH.264/H.265
Video intelligence analyticYes
Video motion detectionYes
Web browserYes
Web-based managementYes
Weight1100
White balanceATW/AWC
Zoom capabilityYes
Specs
Category CodeFNC
Description

5MP Indoor Dome Network Camera with AI engine

  • 5MP Indoor Dome camera
  • Up to 9 Edge AI analytic apps
  • Compatible with AI On-site learning app
  • Enables AI image analysis on non-AI cameras (with AI Processing Relay app)
  • IK10 certified
  • Built-in FIPS 140-2 Level 3 Certified SecureElement
  • (EdgeLock® SE050F NXP® Semiconductors)
  • NDAA Compliant

NameNET CAMERA 5MP BULLET AI OUTD./WV-X22500-V3L I-PRO
PictureUrlhttps://static.elko.cloud/ProductImages/e2a26815-1dc4-4d1d-97f7-f35628279fce.Jpeg
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/e2a26815-1dc4-4d1d-97f7-f35628279fce.Jpeg
Unit Calculated Volume0.00459
Unit Calculated Weight1.5
Units per Pallet0
Units per Shipping Box1
Vendor Homepagehttps://i-pro.com/products_and_solutions/us-en/surveillance/products/wv-x22500-v3l
