NET CAMERA Q6225-LE PTZ 50HZ/NM 02316-301 AXIS

NET CAMERA Q6225-LE PTZ 50HZ/NM 02316-301 AXIS
NET CAMERA Q6225-LE PTZ 50HZ/NM 02316-301 AXIS
  • Connectivity technology: Wired
  • Zoom capability: Yes
  • Maximum resolution: 1920 x 1080
  • Ethernet LAN: Yes
Врз основа на 0 коментари. - Напиши коментар
228,518ден.
  • Достапност:
  • Бренд: AXIS
  • Шифра: 433712
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Axis 02316-002. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Grey, Form factor: Box. Minimum illumination: 0.05 lx, Lens viewing angle, horizontal: 63.8°, Lens viewing angle, vertical: 37°. Sensor type: CMOS, Optical sensor size: 25.4 / 2 mm (1 / 2"). Optical zoom: 31x, Digital zoom: 12x, Focal length range: 6.91 - 214.64 mm
  • Vendor Homepage: https://www.axis.com/products/axis-q6225-le
  • Name: NET CAMERA Q6225-LE PTZ 50HZ/NM 02316-301 AXIS
  • Category Code: FNC
  • Model: 02316-301
  • Form factor: Box
  • Mounting type: Wall
  • Product colour: Grey
  • Housing material: Aluminium
  • International Protection (IP) code: IP66, IP68
  • IK code: IK10
  • Type: IP security camera
  • Connectivity technology: Wired
  • Placement supported: Outdoor
  • PTZ control: Yes
  • Auto-tracking: Yes
  • Tour recording: Yes
  • Wide Dynamic Range (WDR): Yes
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes
  • Built-in processor: Yes
  • Processor model: ARTPEC-7
  • Languages support: Czech/Dutch/English/Finnish/French/German/Italian/Japanese/Korean/Portuguese/Russian/Simplified Chinese/Spanish/Swedish/Thai/Traditional Chinese/Turkish/Vietnamese
  • Number of languages: 18
  • Certification: EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(B), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
  • Camera pan control: Yes
  • Camera tilt control: Yes
  • Minimum illumination: 0.05
  • Lens viewing angle, horizontal: 63.8
  • Lens viewing angle, vertical: 37
  • Tilt angle range: -90 - 90
  • Tilt speed: 150
  • Pan speed: 150
  • Camera shutter speed: 1/111000 - 1/2
  • Optical sensor size: 1/2
  • Progressive scan: Yes
  • Sensor type: CMOS
  • Zoom capability: Yes
  • Optical zoom: 31
  • Digital zoom: 12
  • Focal length range: 6.91 - 214.64
  • Auto focus: Yes
  • Maximum aperture number: 4.6
  • Minimum aperture number: 1.36
  • Night vision: Yes
  • Night vision distance: 400
  • LED type: IR
  • Infra-red wavelength: 850
  • Maximum resolution: 1920 x 1080
  • Video compression formats: H.264/H.265/M-JPEG
  • Video recording: Yes
  • Frame rate: 50
  • Video streaming: Yes
  • Privacy masking: Yes
  • Ethernet LAN: Yes
  • Ethernet interface type: Gigabit Ethernet
  • Networking standards: IEEE 802.1x/IEEE 802.3bt
  • Supported network protocols: IPv4/v6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSb, TLSb, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS
  • Quality of Service (QoS) support: Yes
  • Card reader integrated: Yes
  • Compatible memory cards: SD/SDHC/SDXC
  • Flash memory: 512
  • Internal memory: 1024
  • Ethernet LAN (RJ-45) ports: 1
  • Password protection: Yes
  • Digest authentication: Yes
  • HTTPS encryption: Yes
  • IP address filtering: Yes
  • Network access storage (NAS): Yes
  • Pixel counter: Yes
  • Video motion detection: Yes
  • Power source type: PoE
  • AC input voltage: 100 - 240
  • Power consumption (typical): 25
  • Power consumption (max): 71
  • Operating temperature (T-T): -50 - 55
  • Storage temperature (T-T): -40 - 65
  • Operating relative humidity (H-H): 10 - 100
  • Width: 313
  • Depth: 210
  • Height: 330
  • Weight: 8700
  • Number of cameras: 1
  • Cables included: LAN (RJ-45)
  • Manual: Yes
  • Packaging content: Windows decoder 1-user license, IK10 bumper, High PoE Midspan 1-port
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.0417
  • Unit Calculated Weight: 10.2
Specifications
AC input voltage100 - 240
Auto focusYes
Auto-trackingYes
Built-in processorYes
Cables includedLAN (RJ-45)
Camera pan controlYes
Camera shutter speed1/111000 - 1/2
Camera tilt controlYes
Card reader integratedYes
CertificationEN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(B), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
Compatible memory cardsSD/SDHC/SDXC
Connectivity technologyWired
Day/night modeYes
Depth210
Digest authenticationYes
Digital zoom12
Ethernet interface typeGigabit Ethernet
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Flash memory512
Focal length range6.91 - 214.64
Form factorBox
Frame rate50
Height330
Housing materialAluminium
HTTPS encryptionYes
IK codeIK10
Infra-red wavelength850
Infrared (IR) cut-off filterYes
Internal memory1024
International Protection (IP) codeIP66, IP68
IP address filteringYes
Languages supportCzech/Dutch/English/Finnish/French/German/Italian/Japanese/Korean/Portuguese/Russian/Simplified Chinese/Spanish/Swedish/Thai/Traditional Chinese/Turkish/Vietnamese
LED typeIR
Lens viewing angle, horizontal63.8
Lens viewing angle, vertical37
ManualYes
Maximum aperture number4.6
Maximum resolution1920 x 1080
Minimum aperture number1.36
Minimum illumination0.05
Mounting typeWall
Network access storage (NAS)Yes
Networking standardsIEEE 802.1x/IEEE 802.3bt
Night visionYes
Night vision distance400
Number of cameras1
Number of languages18
Operating relative humidity (H-H)10 - 100
Operating temperature (T-T)-50 - 55
Optical sensor size1/2
Optical zoom31
Packaging contentWindows decoder 1-user license, IK10 bumper, High PoE Midspan 1-port
Pan speed150
Password protectionYes
Pixel counterYes
Placement supportedOutdoor
Power consumption (max)71
Power consumption (typical)25
Power source typePoE
Privacy maskingYes
Processor modelARTPEC-7
Product colourGrey
Progressive scanYes
PTZ controlYes
Quality of Service (QoS) supportYes
Sensor typeCMOS
Storage temperature (T-T)-40 - 65
SummaryAxis 02316-002. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: Grey, Form factor: Box. Minimum illumination: 0.05 lx, Lens viewing angle, horizontal: 63.8°, Lens viewing angle, vertical: 37°. Sensor type: CMOS, Optical sensor size: 25.4 / 2 mm (1 / 2"). Optical zoom: 31x, Digital zoom: 12x, Focal length range: 6.91 - 214.64 mm
Supported network protocolsIPv4/v6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSb, TLSb, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS
Tilt angle range-90 - 90
Tilt speed150
Tour recordingYes
TypeIP security camera
Video compression formatsH.264/H.265/M-JPEG
Video motion detectionYes
Video recordingYes
Video streamingYes
Weight8700
Wide Dynamic Range (WDR)Yes
Width313
Zoom capabilityYes
Specs
Category CodeFNC
Description

This heavy-duty PTZ camera meets the MIL-STD-810G standard, ensuring reliable operation in the toughest conditions. It offers HDTV 1080p resolution and a 1/2" sensor with 31x optical zoom. Featuring Lightfinder, Forensic WDR, and OptimizedIR it ensures sharp, clear images in any light conditions. This vandal-resistant, IK10-rated camera is resistant to both impacts and harsh weather conditions including wind speed up to 245 km/h (150 mph). It comes with built-in analytics preinstalled to alert you when needed. Additionally, Zipstream with H.264/ H.265 significantly reduces bandwidth and storage requirements without compromising image quality.

Model02316-301
NameNET CAMERA Q6225-LE PTZ 50HZ/NM 02316-301 AXIS
PictureUrlhttps://static.elko.cloud/ProductImages/0b1e3445-24dd-4d52-af1f-539706c237ea.Jpeg
thumbnailImagePathhttps://static.elko.cloud/ProductImagesThumbs/0b1e3445-24dd-4d52-af1f-539706c237ea.Jpeg
Unit Calculated Volume0.0417
Unit Calculated Weight10.2
Units per Shipping Box1
Vendor Homepagehttps://www.axis.com/products/axis-q6225-le
