NET SWITCH 8PORT 10/100/TSW030 TELTONIKA

Technical Specifications

• Summary: Teltonika Switch TSW030 8x RJ45 100Mb/s, IP30. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 2048 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 7 - 57 V
• Vendor Homepage: https://teltonika-networks.com/products/ethernet-switches/TSW030/
• Name: NET SWITCH 8PORT 10/100/TSW030 TELTONIKA
• Category Code: SWI
• Model name: TSW030
• Switch type: Unmanaged
• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
• Fast Ethernet (copper) ports quantity: 8
• Networking standards: IEEE 802.3/IEEE 802.3ab/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x
• Ethernet LAN data rates: 10,100
• Switching capacity: 20
• MAC address table: 2048
• Jumbo frames support: Yes
• Jumbo frames: 9216
• Product colour: Black
• Housing material: Aluminium
• Reset button: Yes
• LED indicators: LAN/Power/Status
• DIN rail mounting: Yes
• Power source: DC
• DC input voltage: 7 - 57
• Operating temperature (T-T): -40 - 75
• Operating relative humidity (H-H): 10 - 90
• Certification: CE, UKCA, EAC, UCRF, RCM, FCC, IC, CB Standards EN 55032:2015+A11:2020; EN 55035:2017+A11:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021;
• Units per Shipping Box: 1
• Unit Calculated Volume: 0.00052
• Unit Calculated Weight: 1
