NET CAMERA P1518-E BOX/02758-001 AXIS

NET CAMERA P1518-E BOX/02758-001 AXIS
NET CAMERA P1518-E BOX/02758-001 AXIS
  • Connectivity technology: Wired
  • Zoom capability: Yes
  • Maximum resolution: 3840 x 2160
  • Total megapixels: 8
  • Ethernet LAN: Yes
Врз основа на 0 коментари. - Напиши коментар
113,935ден.
  • Достапност:
  • Бренд: AXIS
  • Шифра: 450290
  • Гарантен рок: 12 месеци
  • Достава: 13-16 дена
Во кошничка
Листа на желби Спореди
1

Technical Specifications

  • Summary: Axis P1518-E. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Box. Minimum illumination: 0.01 lx, Lens viewing angle, horizontal: 113.8 - 45.5°, Lens viewing angle, vertical: 61.9 - 25.8°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.2 mm (1 / 1.2"). LED type: IR
  • Vendor Homepage: https://www.axis.com/products/axis-p1518-e
  • Name: NET CAMERA P1518-E BOX/02758-001 AXIS
  • Category Code: FNC
  • Model: 02758-001
  • Form factor: Box
  • Mounting type: Wall
  • Product colour: White
  • Housing material: Aluminium/Plastic
  • International Protection (IP) code: IP66, IP67
  • IK code: IK10
  • Type: IP security camera
  • Connectivity technology: Wired
  • Placement supported: Outdoor
  • Wide Dynamic Range (WDR): Yes
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes
  • Built-in processor: Yes
  • Processor model: ARTPEC-8
  • Camera pan control: Yes
  • Camera tilt control: Yes
  • Minimum illumination: 0.01
  • Lens viewing angle, horizontal: 113.8 - 45.5
  • Lens viewing angle, vertical: 61.9 - 25.8
  • Tilt angle range: -15 - 15
  • Pan range: -15 - 15
  • Number of sensors: 2
  • Optical sensor size: 1/1.2
  • Sensor type: CMOS
  • Zoom capability: Yes
  • Night vision: Yes
  • LED type: IR
  • Maximum resolution: 3840 x 2160
  • Total megapixels: 8
  • Video compression formats: H.264/H.265/M-JPEG
  • Video recording: Yes
  • Frame rate: 30
  • Video streaming: Yes
  • Noise reduction: Yes
  • Noise reduction technology: 2D noise reduction,3D noise reduction
  • Gain control type: Auto
  • Image quality adjustment: Brightness/Contrast/Saturation/Sharpness/White balance
  • Text caption overlay: Yes
  • Audio system: 2-way
  • Audio system full duplex: Yes
  • Signal-to-Noise Ratio (SNR): 55
  • Ethernet LAN: Yes
  • Ethernet interface type: Fast Ethernet/Gigabit Ethernet
  • Networking standards: IEEE 802.1ar/IEEE 802.1x/IEEE 802.3af/IEEE 802.3at
  • Quality of Service (QoS) support: Yes
  • Card reader integrated: Yes
  • Compatible memory cards: MicroSD (TransFlash)/MicroSDHC/MicroSDXC
  • Flash memory: 8192
  • RAM capacity: 2048
  • Ethernet LAN (RJ-45) ports: 1
  • RS-485 ports: 2
  • Terminal block port: Yes
  • DC-in jack: Yes
  • Cloud-managed: Yes
  • Power source type: DC,PoE
  • Power consumption (typical): 13.2
  • Power consumption (max): 25.5
  • DC output voltage: 10,12,15,16,24,28
  • Operating temperature (T-T): -40 - 60
  • Storage temperature (T-T): -40 - 65
  • Operating relative humidity (H-H): 10 - 100
  • Storage relative humidity (H-H): 5 - 95
  • Weight: 3650
  • Number of cameras: 1
  • Mounting kit: Yes
  • Manual: Yes
  • Units per Pallet: 0
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.03156
  • Unit Calculated Weight: 5
Specifications
Audio system2-way
Audio system full duplexYes
Built-in processorYes
Camera pan controlYes
Camera tilt controlYes
Card reader integratedYes
Cloud-managedYes
Compatible memory cardsMicroSD (TransFlash)/MicroSDHC/MicroSDXC
Connectivity technologyWired
Day/night modeYes
DC output voltage10,12,15,16,24,28
DC-in jackYes
Ethernet interface typeFast Ethernet/Gigabit Ethernet
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Flash memory8192
Form factorBox
Frame rate30
Gain control typeAuto
Housing materialAluminium/Plastic
IK codeIK10
Image quality adjustmentBrightness/Contrast/Saturation/Sharpness/White balance
Infrared (IR) cut-off filterYes
International Protection (IP) codeIP66, IP67
LED typeIR
Lens viewing angle, horizontal113.8 - 45.5
Lens viewing angle, vertical61.9 - 25.8
ManualYes
Maximum resolution3840 x 2160
Minimum illumination0.01
Mounting kitYes
Mounting typeWall
Networking standardsIEEE 802.1ar/IEEE 802.1x/IEEE 802.3af/IEEE 802.3at
Night visionYes
Noise reductionYes
Noise reduction technology2D noise reduction,3D noise reduction
Number of cameras1
Number of sensors2
Operating relative humidity (H-H)10 - 100
Operating temperature (T-T)-40 - 60
Optical sensor size1/1.2
Pan range-15 - 15
Placement supportedOutdoor
Power consumption (max)25.5
Power consumption (typical)13.2
Power source typeDC,PoE
Processor modelARTPEC-8
Product colourWhite
Quality of Service (QoS) supportYes
RAM capacity2048
RS-485 ports2
Sensor typeCMOS
Signal-to-Noise Ratio (SNR)55
Storage relative humidity (H-H)5 - 95
Storage temperature (T-T)-40 - 65
SummaryAxis P1518-E. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Box. Minimum illumination: 0.01 lx, Lens viewing angle, horizontal: 113.8 - 45.5°, Lens viewing angle, vertical: 61.9 - 25.8°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.2 mm (1 / 1.2"). LED type: IR
Terminal block portYes
Text caption overlayYes
Tilt angle range-15 - 15
Total megapixels8
TypeIP security camera
Video compression formatsH.264/H.265/M-JPEG
Video recordingYes
Video streamingYes
Weight3650
Wide Dynamic Range (WDR)Yes
Zoom capabilityYes
Specs
Category CodeFNC
Description

Ideal for building and perimeter protection, this dual-sensor, AI-powered box camera offers both wide-angle and close-up views of the same scene. It delivers excellent image quality under challenging light conditions.

Excellent wide-angle and close-up images 24/7
AXIS P1518-E lets you see it all. With two sensors, you get both wide-angle and close-up views of the same scene. One 1/1.2” image sensor offers exceptional low-light sensitivity and 8 MP at 30 fps for excellent wide-angle images . The other 1/2.8” sensor delivers 2 MP at 60 fps for close-up images without motion blur. It’s perfect at entrances and property fences, where you can monitor the wide-angle overview and get a close-up view of anyone approaching. In addition, Lightfinder 2.0 and Forensic WDR ensure true colors and great forensic detail in challenging light or near darkness.

Smart investment: cost-efficient and robust
AXIS P1518-E offers easy installation with lower total cost of ownership. With two sensors in one camera, there’s only one camera to install, one cable to draw, one IP address, one VMS license, and one license for any analytics you choose to install. Plus, you only need to maintain one camera. Thanks to remote zoom and focus capabilities, it ensures fast and accurate installation. Robust and outdoor-ready, it can be installed, for instance, at intersections to monitor traffic flow and capture vehicle details. Furthermore, this IP66-, IP67-, IK10- and NEMA 4X-rated camera can withstand hurricane winds up to 60 m/s (134 mph).

AI-powered analytics with strong security
This high-performance camera includes a deep learning processing unit (DLPU). This enables improved processing and storage capabilities allowing you to collect and analyze even more data than before - on the edge. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. With AXIS Object Analytics preinstalled, it can detect and classify humans, vehicles, and types of vehicles - all tailored to your specific needs. Furthermore, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations.

  • Two sensors for wide-angle and close-up views
  • Excellent image quality in challenging light
  • AI-powered analytics
  • Low Total Cost of Ownership (TCO)
  • Built-in cybersecurity with Axis Edge Vault
