NET SWITCH 4PORT POE+ D8004/02101-002 AXIS

Technical Specifications

• Summary: Axis 02101-002. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 4. Networking standards: IEEE 802.3af, IEEE 802.3at. Power connector: DC-in jack. Power over Ethernet (PoE)
• Vendor Homepage: https://www.axis.com/
• Name: NET SWITCH 4PORT POE+ D8004/02101-002 AXIS
• Category Code: SWI
• Model name: D8004
• Switch type: Unmanaged
• Basic switching RJ-45 Ethernet ports quantity: 4
• Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
• Power connector: DC-in jack
• Networking standards: IEEE 802.3af/IEEE 802.3at
• Ethernet LAN data rates: 10,100
• Product colour: White
• Housing material: Metal
• LED indicators: Activity/Network/PoE/Power
• Power supply included: Yes
• AC input voltage: 100 - 240
• AC input frequency: 50 - 60
• Power consumption (max): 62
• Power over Ethernet (PoE): Yes
• Power over Ethernet plus (PoE+) ports quantity: 4
• Power over Ethernet (PoE) power per port: 30
• Total Power over Ethernet (PoE) budget: 60
• Operating temperature (T-T): 0 - 50
• Storage temperature (T-T): -10 - 50
• Operating relative humidity (H-H): 5 - 95
• Storage relative humidity (H-H): 5 - 95
• Width: 90
• Depth: 80
• Height: 21
• Weight: 172
• Cables included: AC
• User guide: Yes
• Certification: EN 55022:2010/55032:2012 + AC : 2013 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3, EN 50581, FCC Part 15 Subpart B Class B, ICES-003 Class B, IEC/EN/UL 60950-1, CE, WEEE, C-Tick/RCM
• Harmonized System (HS) code: 85176990
• Units per Shipping Box: 1
• Unit Calculated Volume: 0.002368
• Unit Calculated Weight: 0.857
